Rezistente Heater cartridge length 130mm Power 400W

Heater cartridge length 130mm Power 400W
Diameter 20 mm Length 130 mm Power 400 W 250 mm long wire Load 6 (W / cm)
Standard product not available in stock Technocom Liv Cartridge Heaters Wholesale

https://www.rezistenteelectrice.ro/cat/magazin-rezistente-electrice-industriale-de-incalzit/rezistenta-electrica-incalzit-corpuri-solide/rezistenta-electrica-tip-cartus/rezistenta-electrica-incalzire-cartus-tipuri/rezistenta-cartus-standard-220-volti/cartridge-heaters-high-density-diameter-20mm/ http://www.tehnocomliv.ro/rez_electrice_solide.php#:~:text=Cartuse%20incalzitoare
Diametru 20 mmLungime 130 mm
Putere 400 W
Fir lung 250 mm
Sarcina 6 (W / cm)
Produs standard nedisponibil in stoc Standard Cartridges Heater cartridge length 130mm Power 400W Our Standard Cartridge heaters are designed as an economical, quality heater for lower temperature use 50 watts per square inch, depending on the application. The Standard Cartridge Heater is made to withstand a sheath temperature of up to 1050 F (538 C), internally up to 1200 F (649 C), and features a stainless steel sheath for resistance to oxidation. High-purity magnesium oxide (MgO) fills any space around the resistor wire in order to optimize heat transfer and increase the life of the heater. Features - Benefits - Cartridge heaters high density Diameter 16mm  Computer designed specifications.
Incoloy sheath-tube for oxidation resistance.
Unique winding design allows faster heating and longer life
Fine grain high purity magnesium oxide (MgO) fills any voids around the resistor wire to optimize heat transfer, dielectric strength and life of the heater. Cement seal is standard, RTV and Epoxy seals also available.
Another techical details  Standard Computer designed specifications.Stainless steel sheath for oxidation resistance.Unique winding design allows faster heating and longer life. Fine grain high purity magnesium oxide (MgO) fills any voids around the resistor wire to optimize heat transfer, dielectric strength and life of the heater.Resistor wire is joined to the leads by placing each end into nickel chromium which, upon crimping, affords a positive and consistent junction. Ceramic cap standard; cement, epoxy or RTV seal also available. Disc end of the heater rests on a mica insulator and is held in position when the sheath is rolled over onto it. This is a standard assembly procedure unless the application requires moisture or waterproof sealing, at which time the end cap can be sealed by brazing or welding.
